Incredible cutting of both very thick solid wood and panels, even those veneered, thanks to the new saw unit with ablade that has a maximum diameter of 315 mm with the scoring blade fitted.
New scoring unit that can easily be adjusted from outside the machine, supplied on request.
Easier, more precise cutting: a perfectly stable support is guaranteed, even for large workpieces, by the very wide sliding table and the large squaring frame (960 x 600 mm) provided as standard.
Perfect parallel cuts thanks to the anodized aluminium parallel fence with support, quick locking device andmicrometric adjustment. Precise and rapid positionings: the fence slides fluidly on a 45 mm diameter round bar in rectified steel.
Extraordinary power: the 5kW (6,6hp) 50Hz – 6kW (8hp) 60Hz three-phase motors are provided as standard.
| sc 3 classic | ||
| Max. saw blade diameter with scoring blade fitted | 315 | mm |
| Max. saw blade projection from table at 90°/45° | 100/80 | mm |
| Squaring stroke | 2310 ÷ 2660 | mm |
| Cutting width on parallel fence | 900 ÷ 1270 | mm |
| Three-phase motor starting from | 5 (6) kW – 50 (60) Hz |
